Product Description
BRAND : AIRTECH
MODEL : T15 (2' x 4')
FEATURES :
- EQUIPPED WITH HEPA OR ULPA FILTER.
-THE SINGLE-PHASE MOTOR HAS THREE SPEED LEVELS. AIR VELOCITY AND VOLUME CAN BE ADJUSTED TO MEET DIFFERENT SITUATION.
-OPTION: PRE-FILTER, COUPLING, TOUCH PANEL
-THE STRONG CONFIGURATION CAN WITHSTAND THE WEIGHT OF A PERSON WHILE INSTALLATION AND REPLACEMENT.
-SPECIAL INLET DESIGN CAN MINIMIZE PRESSURE DROP AND NOISE.
-BUILT-IN WIND DEFLECTOR, ANTI-AGING, LOWER AIRFLOW RESISTANCE, EXLCELLENT SOUND INSULATION.
-BUILT-IN DIFFUSER PLATES, WIND PRESSURE DIFFUSES EVENLY, AIR VELOCITY DISTRIBUTES EVENLY.
-HIGH QUALITY BLOWER AND EFFICIENT MOTOR HELP LOWER THE ENERGY CONSUMPTION.
-LOW HEIGHT, SAVE SPACE, ONLY 13.3CM THICKNESS.
-CAPABLE OF SUPPORTING ANY CLEANROOM CONFIGURATION.
-THE DIMENSIONS OF THE FFE CAN BE CUSTOMIZED.
SPEC.:
-STRUCTURE : COLD-ROLLED STEEL / STAINLESS STEEL SUS430 / ALUMINUM ALLOY / AL-ZN ALLOY COATED STEEL.
-DIMENSION : 575(W)x1175(L)
-POWER : 110 / 220V 1Φ 60Hz, 220 / 280V 3Φ 60Hz
-SPEED LEVELS : HIGH MIDDLE LOW SINGLE SPEED
-ELECTRIC CURRENT (A) 1.3/0.65 1.05/0.55 0.96/0.5 0.48/0.28
-POWER CONSUMPTION (VA) 165 135 122 210
-TOTAL PRESSURE (mmAq) 28 26 24 26
-AIR VELOCITY (M/S) 0.46 0.38 0.31 0.4
-AIR VOLUME (CMM) 17 14 11.5 15
-NOISE (dB(A)) 52 49 46 50
-OUTPUT POWER (W) 85 85 85 70
-ROTATION SPEED (RPM) 1100 1000 900 1050
-MOTOR EFFICIENCY (%) 60 57 46.5 57.5
-WEIGHT (KG) ABOUT 32KG ( CASE : 27 + FILTERE : 5)
Frequently Purchase Together
3A-8417950
BRAND : AIRTECH
TOTAL THERE ARE 4 MODEL :
MODEL 1 : 3A-8417950 (840X1790X50t)
MODEL 2 : 3A-5711750 (570x1170x50t)
MODEL 3 : 3A-11711750 (1170x1170x50t)
MODEL 4 : 3A-616150 (610x610x50t)
